Intel R1208WFTYS S2600WFT 19" 1U 8x 2,5" SFF SAS NVMe 2x Intel XEON Scalable LGA3647 DDR4 4 ECC Raid 2x PSU
Product description
Vendor: Intel
Unit type: Server
Type: 19" 1 HE
Model: S2600WFT R1000WFR
HDD bays: 8x HotSwap HDD Bays SAS/S-ATA Backplane
without selected hdds or trays are no hdd trays included in delivery
without selected hdds or trays are no hdd trays included in delivery
RAM: DDR4 registered ECC (PC4-2400T default memory speed with RAM selection)
Optical drive: ohne
Networking: 2x 10GbE LAN (RJ-45)
Internal interfaces:
Information:
2x FCLGA3647 Intel CPU Sockel für Skalierbare Intel® Xeon® Prozessoren
24x DDR4 288-pin ECC DIMM Banks up to 1,5TB RAM
8x 2,5" SFF SAS/SATA/NVMe Backplane
(SATA onboard; controller for SAS required; cables & controller for NVMe required)
Intel C624 chipset
Integrated IPMI 2.0 and KVM with Dedicated LAN (AST2500)
4x OCuLink PCIe connectors onboard
(CPU1 + CPU2 is needed to use more than one PCIe Controller)
2x Riser interface:
Primary Riser 1 CPU 1
Primary Riser 1 Slot 2 CPU 1:
1. PCIe 3.0 x16 - x16 Connector - Full-height,Half-length slot
Primary Riser 1 CPU 2
Primary Riser 1 Slot 1 CPU 2:
1. PCIe 3.0 x16 - x16 Connector - Full-height,Half-length slot
2x M.2 2280
Information:
2x FCLGA3647 Intel CPU Sockel für Skalierbare Intel® Xeon® Prozessoren
24x DDR4 288-pin ECC DIMM Banks up to 1,5TB RAM
8x 2,5" SFF SAS/SATA/NVMe Backplane
(SATA onboard; controller for SAS required; cables & controller for NVMe required)
Intel C624 chipset
Integrated IPMI 2.0 and KVM with Dedicated LAN (AST2500)
4x OCuLink PCIe connectors onboard
(CPU1 + CPU2 is needed to use more than one PCIe Controller)
2x Riser interface:
Primary Riser 1 CPU 1
Primary Riser 1 Slot 2 CPU 1:
1. PCIe 3.0 x16 - x16 Connector - Full-height,Half-length slot
Primary Riser 1 CPU 2
Primary Riser 1 Slot 1 CPU 2:
1. PCIe 3.0 x16 - x16 Connector - Full-height,Half-length slot
2x M.2 2280
External interfaces:
5x USB 3.0 (3x rear)
2x RJ-45 LAN 10 Gigabit
1x RJ45 Dedicated IPMI LAN port
1x VGA 15pol. D-SUB
5x USB 3.0 (3x rear)
2x RJ-45 LAN 10 Gigabit
1x RJ45 Dedicated IPMI LAN port
1x VGA 15pol. D-SUB
Videocard: onboard Aspeed AST2500 BMC
Powerunits: up to 2x 1100W HotSwap Power Supply
Net weight: 10,41 kg
Installation depth: 74,5 cm
Dimensions: L: 78 cm | B: 48,5 cm | H: 4,5 cm
Compatible operating systems:
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmoxx; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmoxx; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Item condition: refurbished, Grade A
Every device has been cleaned and carefully checked before delivery. Latest free available firmware has been flashed on systembios, storage-, network- and management controller.
Every device has been cleaned and carefully checked before delivery. Latest free available firmware has been flashed on systembios, storage-, network- and management controller.
manufacturer information:
info.de@intel.com
Intel Deutschland GmbH
Am Campeon 10
85579 Neubiberg
Deutschland
Product No.: SK0513
Base price: 242,00 €
incl.
19% MwSt | excl. Shipping
Price excl. VAT: 203,36 €
Availability:
Shipping time: 2-5 days + shipping time (excl. weekend, excl. business holidays)
Weight KG: 26.00kg
